Quick Details

  • Condition: New
  • Machine Type: Glass Tempering Furnace
  • Production Capacity: 98%
  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: Mingsite
  • Model Number: MF-F1325-4T
  • Voltage: 380v
  • Power(W): 470kw
  • Dimension(L*W*H): 13120mm(L)*7870mm(W)*2500mm(H)
  • Weight: 10T
  • Certification: CE
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • model: MF-F1325-4T
  • certification: CE/ISO
  • power: 470kw
  • productivity: 98%
  • serive: on-site installation and training
  • glass thickness range: 4.0-19.0mm
  • guarantee period: 1 year
  • color: by order
  • voltage: 380v
  • control technique: variable frequency

Packaging & Delivery

Packaging Details: glass tempering furnace/ packed in container or by customers' require
Delivery Detail: 60 days after receive down payment for glass tempering furnace

Specifications

1.Power:470kw
2.Productivity:98%
3.CE/ISO/CCC
4.On-site installation and training



Our Services

 Zhangjiagang mingsite glass Machinery company is responsible for on-site installation and training workers of buyer.





Product Description

Flat glass machines can manufacture high-quality glass of every kind dimensions and it canalso produce low-e glass ,film-coating glass,etc.  Which is widely used in construction safety glass,doors,windows curtain wall.







2014 China Factory Hot Sell Low Price CE Flat Glass Tempering Furnace

 Better machine  Better benefit









Main Technical Parameters



ModelMF-F1325-4TBrandMingsite
Voltage380VPower470KW
External Dimension13120mm(L)*7870mm(W)*2500m(H) OriginZhangjiagang  Jiangsu
Thickness4.0-19.0mmWarranty1 year

Heating Power

340kwCooling Power100kw

 Air temperature

22 - 25°CServiceon-site installation

Yield rate

97%Energy consumption

≤4KW/hour/square meter



 1. Equipment External Dimension: 13120mm(L)*7870mm(W)*2500mm(H)

  2.  Installed Capacity:

       Power Supply: Three-phase 380V  Four-wire 50 Hz

       Gross Power: 470KW

   a.Heating: 340KW

   b.Cooling: 100KW×1set

   c.Air Compressor: 7kg/cm  0.5KW, including the freeze drier and 1T air collector

  3.Compressed air pressure of actuating mechanism: <7kg/cm2

  4.Compressed air volume of actuating mechanism: <150L/min.

  5.Air volume for thermal agitation: <2000L/min.

     Maximum noise produced by the production line: <115db

  6.The ambient temperature should be controlled between 22 to 25°C.



Characteristics

Logical structure, simple manipulation, strong stability, outstanding energy-saving. It is able to manufacture high-quality glass of every kind dimensions and it can also manufacture LOW-E glass, embossing glass, film coating glass, etc.



Application

a.construction safety glass

b.doors ,windows and curtain walls
c. hollow, laminated glass deep-processing products, such as substrate and so on


Warranty

Full 1-year warranty

Providing installation and training



Transformer configuration
Customers need to configure 400KVA transformer, the minimum shall not be less than 300KVA.



Technical specifications of the same serise



Model

 MAX

mm

MIN

mm

   Gass thickness

 mm

Capacity

  m2/h

Heating

  KW

Quench

   KW

 MF-F0610-3T 600*1000 60*60 2.85-12.0 9 55 35
 MF-F1325-3T 1300*2500 100*200 3.0-19.0 48 230 160*2
 MF-F1325-4T 1300*2500 100*200 4.0-19.0 48 230 132
 MF-F1332-4T 1300*3200 100*200 4.0-19.0 60 280 160
 MF-F1625-4T 1600*2500 100*200 4.0-19.0 60 300 132
 MF-F1632-4T 1600*3200 100*200 4.0-19.0 75 320 160
 MF-F1642-4T 1800*4200 100*200 4.0-19.0 100 450 220
 MF-F1650-4T 1600*5000 100*200 4.0-19.0 120 540 250
 MF-F2436-4T 2440*3660 100*250 4.0-19.0 135 560 250
 MF-F2436-5T 2440*3660 100*250 5.0-19.0 135 560 132
 MF-F2442-4T 2440*4200 100*250 4.0-19.0 160 650 185
 MF-F2442-5T 2440*4200 100*250 5.0-19.0 160 650 132
 MF-F2450-4T 2440*5000 100*250 5.0-19.0 185 700 220
 MF-F2450-5T 2440*5000 100*250 5.0-19.0 185 700 160
 MF-F2460-5T 2440*6000 100*250 5.0-19.0 225 900 200
 MF-F2480-5T 2440*8000 100*250 5.0-19.0 300 1200 280
 MF-F3050-5T 3050*5000 100*250 5.0-19.0 215 860 200
 MF-F3060-5T 3050*6000 100*250 5.0-19.0 270 1080 250
 MF-F3080-5T 3050*8000 100*250 5.0-19.0 360 1440

 315



 The Picture Of Machine



Control interface





Packaging & Shipping

  Packing in container or by order



Company Information





Exhibition and Certification





If you have any question ,feel free to contact us.And welcome to our company.





FAQ

 1. How to choose machine?

Answer :Glass tmeperinf furnace is based on the customer's glass size customized . In order to quote you the suitable machine choose the right machine, pls inform us  the max.glass size, thickness , usage, etc.



2.Do you have certification?

Answer: Yes, we have ce .



3. Machines exported to which countries?

Answer: Brazil, United States, Taiwan, Colombia, Mexico, Malaysia and so on.



4.Corporate clients?

The Jordon Glass Corp.

American Glass Products Do Brasil Ltda.

Asahi Glass Co.,Ltd Shenzhen

Taiwan Foxconn

Anhui Huayi

Dongguan Yinte Glass Co.,Ltd
